Current Transformer
Product Details
Application
★ Electricity renovation project(semiconductor, tyre, rubber, polycrystalline silicon)
★ Low voltage distribution system
★ Power operations
★ Data center
Structure
Advantage
1) Small size
2) High precision
3) High capacity
4) Easy installation
Product Selection
|
Type |
Dimension(mm) |
Dia.(mm) |
Error(mm) |
|||||
|
W |
H |
D |
M |
N |
φ1 |
φ2 |
||
|
K-φ10 |
27 |
44 |
32 |
25 |
36 |
10 |
9 |
±1 |
|
K-φ16 |
31 |
50 |
36 |
27 |
42 |
16 |
17 |
±1 |
|
K-φ24 |
39 |
70.5 |
55 |
36 |
52 |
24.5 |
23 |
|
|
K-φ36 |
42 |
81.5 |
66 |
40 |
55.5 |
33 |
35 |
|
|
K-φ24 |
39 |
70.5 |
55 |
36 |
52 |
24.5 |
23 |
±1 |
|
K-φ36 |
42 |
81.5 |
66 |
40 |
55.5 |
33 |
35 |
|
|
K-φ50 |
46.5 |
110 |
90 |
54 |
66.5 |
47 |
52 |
|
|
Type |
Ratio |
Class(VA/Q) |
Dia.(mm) |
||||||
|
0.5 |
1 |
||||||||
|
MKH-0.66/K-φ10 |
5A/1.25mA |
10 |
φ10 |
||||||
|
(10-20)A/5mA |
10 |
φ10 |
|||||||
|
(40-60)A/5mA |
10 |
φ10 |
|||||||
|
MKH-0.66/K-16 |
(20-50)A/10mA |
10 |
φ16 |
||||||
|
(40-100)A/20mA |
10 |
φ16 |
|||||||
|
100A/40mA |
10 |
φ16 |
|||||||
|
MKH-0.66/K-φ24 |
(60-200)A/20mA |
10 |
φ24 |
||||||
|
(100-250)A/40mA |
10 |
φ24 |
|||||||
|
400A/100mA |
10 |
φ24 |
|||||||
|
MKH-0.66/K-φ36 |
(100-200)A/10mA |
10 |
φ36 |
||||||
|
(200-400)A/20mA |
10 |
φ36 |
|||||||
|
(300-600)A/100mA |
10 |
φ36 |
|||||||
|
400A/40m4 |
10 |
φ36 |
|||||||
|
600A/75mA |
10 |
φ36 |
|||||||
|
MKH-0.66/K-φ24 |
(150-200)A/5(1)A |
1 |
φ24 |
||||||
|
(250-300)A/5(1)A |
1.5 |
||||||||
|
MKH-0.66/K-φ36 |
(300-400)A/5(1)A |
1.5 |
φ36 |
||||||
|
(500-600)A/5(1)A |
1.5 |
||||||||
|
MKH-0.66/K-φ50 |
(600-700)A/5(1)A |
2.5 |
φ50 |
||||||
|
(800-900)A/5(1)A |
5 |
||||||||
|
1000A/5(1)A |
10 |
||||||||
|
Type |
Dimension(mm) |
Dia.(mm) |
Error(mm) |
|||
|
W |
H |
D |
a |
e |
||
|
K-30×20 |
90 |
114 |
40 |
22 |
32 |
±1 |
|
K-60×40 |
114 |
140 |
36 |
42 |
62 |
|
|
K-80×40 |
122 |
162 |
40 |
42 |
82 |
|
|
K-80×50 |
114 |
159 |
36 |
52 |
82 |
|
|
K-80×80 |
144 |
159 |
36 |
82 |
82 |
|
|
K-100×40 |
144 |
194 |
52 |
42 |
102 |
|
|
K-120×60 |
164 |
214 |
52 |
62 |
122 |
|
|
K-120×80 |
144 |
199 |
36 |
82 |
122 |
|
|
K-130×40 |
144 |
224 |
52 |
42 |
132 |
|
|
K-130×60 |
170 |
222 |
70 |
60 |
130 |
|
|
K-140×60 |
164 |
234 |
52 |
62 |
142 |
|
|
K-160×80 |
184 |
254 |
52 |
82 |
162 |
|
|
K-200×80 |
184 |
294 |
52 |
82 |
202 |
|
|
Type |
Ratio(A) |
Class |
Burden(VA/Ω |
|
K-30×20 |
20-75/1A |
1.0 |
0.2 |
|
100-150/5(1)A |
1.0 |
1.0 |
|
|
200/5(1)A |
1.0 |
1.5 |
|
|
250-300/5(1)A |
0.5 |
1.5 |
|
|
350-400/5(1)A |
0.5 |
2.5 |
|
|
K-60×40 |
250-300/5(1)A |
1 |
1.5 |
|
350-450/5(1)A |
0.5 |
1.5 |
|
|
500-800/5(1)A |
0.5 |
2.5 |
|
|
1000-1250/5(1)A |
0.5 |
5 |
|
|
1500-2000/5(1)A |
0.5 |
10 |
|
|
K-80×40 |
300-450/5(1)A |
0.5 |
2.5 |
|
500-800/5(1)A |
0.5 |
5.0 |
|
|
1000-2000/5(1)A |
0.5 |
10 |
|
|
2500-3000/5(1)A |
0.2 |
10 |
|
Type |
Ratio(A) |
Class |
Burden(VA/Ω) |
|
K-80×80 |
250-300/5(1)A |
1 |
1.5 |
|
400-450/5(1)A |
0.5 |
1.5 |
|
|
500-800/5(1)A |
0.5 |
2.5 |
|
|
1000/5(1)A |
0.5 |
5 |
|
|
K-100×40 |
1000-2000/5(1)A |
0.5 |
10 |
|
2500-3000/5(1)A |
0.2 |
10 |
|
|
4000-5000A/5(1)A |
0.2 |
15 |
|
|
K-120×60 |
400-450/5(1)A |
0.5 |
2.5 |
|
500-800/5(1)A |
0.5 |
5.0 |
|
|
1000-2000/5(1)A |
0.5 |
10 |
|
|
2500-5000/5(1)A |
0.2 |
10 |
|
|
K-120×80 |
500-800/5(1)A |
0.5 |
2.5 |
|
1000-1200/5(1)A |
0.5 |
5 |
|
|
1250-1500/5(1)A |
0.5 |
7.5 |
|
|
K-130×40 |
1000-2000/5(1)A |
0.5 |
10 |
|
2500-5000/5(1)A |
0.2 |
10 |
|
|
K-130×60 |
1000-2000/5(1)A |
0.5 |
10 |
|
2500-5000/5(1)A |
0.2 |
15 |
|
|
K-140×60 |
1000-2000/5(1)A |
0.5 |
10 |
|
2500-3000/5(1)A |
0.2 |
10 |
|
|
4000-5000/5(1)A |
0.2 |
15 |
|
|
K-160×80 |
1000-2000/5(1)A |
0.5 |
10 |
|
2500-3000/5(1)A |
0.2 |
10 |
|
|
4000-5000/5(1)A |
0.2 |
15 |
|
|
K-200×80 |
1000-2000/5(1)A |
0.5 |
10 |
|
2500-3000/5(1)A |
0.2 |
10 |
|
|
4000-5000/5(1)A |
0.2 |
15 |
|
|
K-P-120×60 |
300-400/5(1)A |
5P10 |
2.5 |
|
400/5(1)A |
2.5 |
||
|
500/5(1)A |
3.75 |
Keywords： Current Transformer
